Description

Yamaha PSR-E583 61-Key Entertainment Keyboard

NEXT LEVEL PERFORMANCE AND EXPRESSION

Designed for aspiring musicians, the Yamaha PSR-E583 is a 61-key portable keyboard packed with features, including a wide selection of Voices and Styles, and optimised for music-making around the world.

Highlights

• Touch sensitive keyboard with 61 keys
• 890 Voices incl. 19 Super Articulation Lite Voices
• 345 auto accompaniment Styles
• Assignable real-time Control Knobs, Motion Effect functionality, pitch bend wheel
• Modulation Wheel
• Mega Boost
• 12W + 12W amplification
• Microphone input and Vocal effects; L&R outputs for connecting to a PA system
• Connectivity for Foot Controller

SOUND LIKE A PRO

EASY TO USE
The clear display and intuitive, user-friendly interface are designed to help you quickly adjust settings, whether you’re creating, practising, or performing for an audience.

WIDE RANGE OF SOUNDS
With a vast selection of Voices—including electric piano, organ, vibraphone, strings, and Super Articulation Lite, which recreates the sound of non-keyboard instruments—along with Style presets, you can play virtually any song or genre at the touch of a button.

DSP EFFECTS
Add depth and energy to your performances by enriching instrument Voices with effects at the touch of the DSP button.

AUTO CHORD
Expand your performance with the Auto Chord Play function, which automatically generates customised chord progressions while you play a Style—so you can experiment freely without worrying about chord changes.

ETHNIC INSTRUMENTS
The PSR-E583 is designed to support music from around the world, from Afrobeats to reed instruments and percussion that deliver a distinctly South American sound.

COMPLETE CONTROL

CONTROL AT YOUR FINGERTIPS
Access immediately to all the most used selections of the keybaord thanks to:
- Live Control Knobs, to assign and alter characteristics of your sound
- Pitch Bend Wheel, to bend the pitch of a note up or down
- Grid Panel Design, to easily access to Voices, Styles and functions
- Motion Effects, to control phasers, tremolo, and other moving effects

REAL-TIME CONTROL
Additionally, exclusive to the PSR-E583 (compared to the PSR-E483)

• Modulation Wheel – Add and adjust effects in real time to shape your sound while performing
• Expression Pedal – Increase or reduce output independently of the master volume, freeing up your hands for expressive control

PERFORMANCE

LOOPER FUNCTION
Free up your hands during performances, practise complex pieces, or build song sections by recording and looping chord progressions, drum patterns, and musical phrases.

QUICK SAMPLING
Explore your creativity by recording a short musical phrase and assigning it to the Quick Sampling button. Tap the SYNC button to ensure your sample starts exactly on the next bar of the Style.

CONNECTIVITY
Plug in a microphone to sing while you play, use the Rec’n’Share app to share your music with the world, and connect to PA systems for live performances on stage.

MIDI SONG TO STYLE APP
Automatically generate Style data from your existing MIDI song library. Easily transform standard MIDI files into dynamic, full-featured Styles, complete with intros, endings, and transitions.

ADDITIONAL BENEFITS

FLOWKEY
Have you always dreamed of playing the piano or keyboard? Learn at your own pace with your favourite music, thanks to Yamaha and flowkey. Purchase a Yamaha digital piano or keyboard, register it on the Yamaha website, and receive three months of premium access to flowkey, including all songs and tutorials. No payment information is required to register.

ONLINE MUSIC LESSON
Get started easily with two free online lessons. Choose your Yamaha Music School teacher and your preferred time through our simple online booking system, and kickstart your musical journey.

PSR-E583

Size/Weight

• Width ~ 992mm (39-1/16")
• Height ~ 136mm (5-3/8")
• Depth ~ 404mm (15-7/8")
• Weight ~ 7.3kg (16lb, 1oz) (not including batteries)

Control Interface

• Keyboard - Number of Keys ~ 61
• Keyboard - Type ~ Organ Style
• Keyboard - Touch Response ~ Yes (Soft, Medium, Hard, Off)

Display

• Type ~ LCD
• Backlight ~ Yes
• Language ~ English

Panel

• Language ~ English

Other Controllers

• Pitch Bend ~ Yes
• Modulation ~ Yes
• Art. Switches ~ Yes
• Control Knobs ~ 2

Voices

• Tone Generation - Tone generating Technology ~ AWM Stereo Sampling
• Polyphony - Number of Polyphony (Max.) ~ 64
• Preset - Number of Voices ~ 890 (352 Voices + 40 Drum/SFXKits + 40 Arpeggio Voices + 458 XGlite Voices)
• Preset - Featured Voices ~ 19 S. Art Lite Voices
• Compatibility - GM ~Yes
• Compatibility - XGlite ~ Yes

Accompaniment Style

• Preset - number of Preset Styles ~ 345
• Preset - Fingering ~ Multi-Finger, Smart Chord
• Preset - Style Control ~ ACMP ON/OFF, SYNC START, SYNC STOP, START/STOP, INTRO/ENDING/rit., MAIN A, MAIN B, TRACK ON/OFF
• Other Features ~ One Touch Setting (OTS) ~ Yes
• Other Features ~ Auto Chord Play ~ 50 Chord Progressions
• Expandability - Expansion Style ~ 10
• Compatibility ~ Style File Format (SFF)

Effects

• Types - DSP ~ DSP1: 41 types + DSP2: 12 types
• Motion Effect ~ 57 types
• Types - Reverb ~ 15 types
• Types - Chorus ~ 7 types
• Types - Master EQ ~ 5 types
• Functions - Dual ~ Yes
• Functions - Split ~ Yes
• Functions - Melody Suppressor ~ Yes
• Harmony/Echo ~ 26 types
• Functions - Arpeggio ~ 164 types

Songs

• Number of Preset Songs ~ 2
• Recording - Number of Songs ~ 10
• Recording - Number of Tracks ~ 6 (5 Melody + 1 Style)
• Recording - Data Capacity ~ Approx. 19,000 notes (total for all 10 Songs)
• Compatible Data Format - Playback ~ SMF Formats 0 & 1
• Compatible Data Format - Recording ~ Original File Format (SMF 0 conversion function)

USB Audio Recorder

• Recording Time (max.) ~ 80 minutes (approx. 0.9 GB) per Song
• Format - Playback ~ WAV (44.1 kHz, 16-bit, stereo)
• Format - Recording ~ WAV (44.1 kHz, 16-bit, stereo)

Quick Sampling

• Sampling Type ~ Oneshot, Loop
• Samples (Preset/User) ~ 4
• Sampling Sources ~ AUX IN, MIC INPUT, USB audio interface, WAV format files
• Sampling Format ~ Original File Format (16-bit, stereo)
• Sampling Rate ~ 44.1 kHz

Functions

• USB audio interface ~ 44.1kHz, 16 bit, stereo
• Registration ~ Number of Buttons ~ 4 (x8 banks)
• Registration ~ Control @ Freeze
• Overall Controls - Metronome ~ Yes
• Overall Controls - Tempo Range ~ 11-280
• Overall Controls - Transpose ~ -12 to 0, 0 to +12
• Overall Controls - tuning ~ 427.0-440.0-453.0 hz (approx 0.2 Hz increments)
• Overall Controls - Octave Button ~ Yes
• Overall Controls ~ Scale type ~ 5
• Miscellaneous - PIANO Button ~Yes
• Miscellaneous - Looper ~Yes
• Miscellaneous - Megaboost ~2 steps (approx. +3 dB, and +6 dB)

Storage and Connectivity

• Storage - Internal Memory ~ Approx. 1.72MB
• Storage - External Drives ~ USB flash drive
• Connectivity -DC In ~ 16 V
• Connectivity - Headphones ~ Standard stereo phone jack
• Connectivity - Foot Switch ~ Yes (Sustain, Arpeggio Hold, Sustain+Arpeggio Hold, Articulation)
• Connectivity - Expression Pedal ~ Yes
• Connectivity - AUX IN ~ Yes (Stereo mini jack x1)
• Connectivity - USB TO DEVICE ~ Yes (USB Type-A)
• Connectivity - USB TO HOST ~ Yes (USB Type-C™)
• Connectivity - LINE OUT ~ Standard stereo phone jacks: L/L+R, R
• Connectivity - Microphone ~ Standard stereo phone jack x 1

Sound System

• Amplifiers ~ 12W x2
• Speakers ~ 12 cm x 2

Power Supply

• Adaptors ~ PA-300C (Output : DC 16 V, 2.4 A)
• Batteries ~ Six "AA" size alkaline (LR6), manganese (R6), or Ni-MH rechargeable batteries (HR6)
• Power Consumption ~ 13 W (when using PA-300C AC adaptor)
• Auto Power Off ~ Yes (Disabled/5/10/15/30/60/120 minutes)

Accessories

• Included ~ Owner’s Manual, Music Rest, AC adaptor
