Mooer Echoverb Digital Delay & Reverb Pedal
Echo Verb combines high-quality reverb and digital delay in a compact pedal format. Each effect can be used independently or together, allowing for flexible sound shaping across a wide range of applications.
The control layout makes it easy to dial in anything from subtle ambient enhancement to more pronounced, effect-heavy sounds. The delay includes a tap tempo function, which can be operated via the footswitch or the central LED button.
With its compact size and versatile functionality, Echo Verb is well suited to small pedalboard setups.
Highlights
- Controls switch:Depicts which effect the controls are adjusting. Switch up to adjust Delay(Tape Echo) parameters switch down to adjust reverb parameters.
- LEVEL/MIX control:Adjusts volume of delay and wet/dry mix of reverb.
- TIME/TONE: Adjusts Delay time(45ms-1600ms) and Reverb tonality.
- FB/DECAY:Adjusts Delay feedbackand Reverb decay（Room-Mountains）.
Tap Tempo Functionality:
- Footswitch Mode:Depressing the footswitch for more than 1 seconds will engage Tap Tempo functionality and the LED will flash. Tap the footswitch two or more times to synchronize the delay to your desired tempo. The pedal will revert back to normal operation after 5 seconds.
- LED Mode: Tap the LED 2 or more times to synchronize the delay to your desired tempo.
MDV1
- Input:1/4” mono audio jack.(Impedance: 470k Ohms)
- Output:1/4” mono audio jack(Impedance: 100 Ohms)
- Power requirements: AC adapter 9V DC , centre negative.
- Highly recommend to use Mooer Micro Power.
- Current Draw:160mA
- Dimensions:93.5mm(D) x 42mm(W) x 52mm(H)
- Weight:146g
